Mesh Belt Annealing Furnace
Mesh belt annealing furnace is designed for quenching and tempering of concrete nails, screw nails and small parts. This furnace equipped with material feeding, quenching furnace, water or oil tank lifting, mesh belt tempering furnace and PID electrical cabinet.
Mesh-belt quenching furnace
| Model No. | TOPS-QF120 | TOPS-QF200 |
| Heating power | 120KW | 200KW |
| Max. operating temperature | 950℃ | 950℃ |
| Working temperature | 750~850℃ | 750~850℃ |
| Temperature control area | Three section | Three section |
| Temperature control tolerance | ±2℃ | ±2℃ |
| Furnace temperature homogeneity | ±5℃ | ±5℃ |
| Mesh width | 400mm | 550mm |
| Mesh material | Stainless steel 314, herringbone | Stainless steel 314, herringbone |
| Driver power | 0.75KW | 0.75KW |
| Muffle effective size | 450x120mm (W*H) | 600x120mm (W*H) |
| Methyl alcohol dosage | App. 3kg/hour | App. 3kg/hour |
| Production capacity | App.150kg/hour | App.250kg/hour |
Mesh-belt tempering furnace
| Model No. | TOPS-TF45 | TOPS-TF75 |
| Heating power | 45KW | 75KW |
| Max. operating temperature | 650℃ | 650℃ |
| Working temperature | 400~500℃ | 400~500℃ |
| Temperature control area | One section | One section |
| Temperature control tolerance | ±2℃ | ±2℃ |
| Furnace temperature homogeneity | ±5℃ | ±5℃ |
| Mesh width | 550mm | 700mm |
| Mesh material | Galvanized A3, herringbone | Galvanized A3, herringbone |
| Driver power | 0.75KW | 0.75KW |
| Circulating fan power | 3.0KW | 3.0KW |
